6 Channel Portable ECG Machine YSECG-06L

Item No.: YSECG-06L
6 Channel Portable ECG Machine Features:7 inch high resolution color touch screen, 12-lead simultaneous acquisition and display,
  • BrandYSENMED
  • Model numberYSECG-06L
  • Warranty1 Year
  • CustomizedOEM
  • Lead time7-10 Days
  • PackageExport carton
  • Description

    6 Channel Portable ECG Machine Features

    7 inch high resolution color touch screen
    12-lead simultaneous acquisition and display
    ECG Automatic measurement and interpretation function
    Complete digital filters, resisting baseline drift, AC and EMG interference
    Compact and lightweight design
    Support USB flash disk and micro SD card to extend memory
    Software upgrade via USB/SD card
    Built-in rechargeable Li-ion battery

    6 Channel Portable ECG Machine Standard Configuration

    Main machine: 1 PC
    Patient cable: 1 PC
    Limb electrode: 1set (4pcs)
    Chest electrode: 1set (6pcs)
    Power cable: 1 PC
    80mm×20M recording paper: 1 PC
    Paper axis: 1 PC
    Power cord: 1 PC

    6 Channel Portable ECG Machine Packing

    Single package size: 32×25×17cm
    Single gross weight: 2.8 KG
    8 unit per carton, package size: 54×33×75cm, total gross weight 22 KG

    6 Channel Portable ECG Machine Specification

    Items    Specification
    Lead    Standard 12 leads
    Acquisition Mode    Simultaneous 12 leads acquisition
    Measurement Range    ±5mVpp
    Input circuit    Floating; Protection circuit against Defibrillator effect
    Input Impedance    ≥50MΩ
    Input circuit current    <0.05μA
    Record mode    Automatic: 3CHx4+1R, 3CHx4, 3CHx2+2CHx3,
    3CHx2+2CHx3+1R, 6CHX2
        Manual: 3CH, 2CH, 3CH+1R, 2CH+1R;
        Any lead selectable.
    Filter    EMG Filter: 25Hz/30Hz/40Hz/75 Hz/100Hz/150Hz
        DFT Filter: 0.05 Hz/ 0.15 Hz
        AC Filter: 50 Hz/60Hz
    CMRR    >100dB
    Patient leak current    <10μA(220V-240V)
    Frequency Response    0.05Hz~150Hz(-3dB)
    Sensitivity    2.5mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV(error: ±5%)
    Anti-baseline Drift    Automatic
    Time constant    ≥3.2s
    Noise level    <15μVp-p
    Paper speed    12.5 mm/s, 25 mm/s, 50 mm/s
    Recording mode    Thermal printing system
    Paper specification    Roll 110mmx20M
    Safety Standard    IEC I/CF
    Sample Rate    Normal: 1000sps/channel
    Power Supply    AC: 100~240V, 50/60Hz, 30VA~100VA
        DC: 14.8V/2200mAh, built-in lithium battery
