Parameter | YSF20DR-B2 | YSF32DR-B2 | YSF50DR-B2 | YSF65DR-B2 |
Max.KW | 20KW | 32KW | 50KW | 65KW |
Power Supply | 50HZ, 60HZ, wire diameter >4mm2, internal resistance<0.52; 20/32/50kW(220V/380V available), 65kW(only 380V) |
|||
mA | 10~250 | 10~400 | 10~630 | 10~800 |
mAS | 0.1~200 | 0.1~320 | 0.4~1000 | 0.4~1000 |
KV | 40~125kV, stepping by 1kV | 40~150kV, stepping by 1kV | ||
Exposure Time | 0.001~10s adjustable: stepping by 1ms | |||
Focus | Dual focus: 1.0*1.0mm/2.0*2.0mm | Dual focus: 0.6*0.6mm/1.2*1.2mm | ||
Rotating Speed & Heat Capacity | 2800prm/1300kHU | 2800prm/1300kHU | ||
Inverter Frequency | 50kHZ~220kHZ | |||
Tube Movement | Up & down lift (Electric), left & right rotation | |||
Column | Left & right movable | |||
Radiography Table | Four-way floating | |||
Bucky Stand | Electric up & down (synchronizes with tube up & down movement) | |||
Detector Size | 17*17 inch | |||
Pixel Resolution | 3072*3072 | |||
Pixel Pitch | 139μm | |||
A/D Conversion | 16bits | |||
Spatial Resolution | 3.6lp/mm | |||
Size | 460*460*15mm | |||
Interface | Wired (Wireless is optional) | |||
Software | Professional medical software with multi-languages available | |||
Workstation | Intel i5 CPU, 8G memory, 2G card, 128G SSD, PCI-E, R232; 22.5 inch display. Other options are available upon request. |
